Incorporating specially designed cycles, the RH-ProVET-9 is faster and more effective than traditional steam sterilizers. The 375°F RapidHeat cycle is perfect for the fast turnaround of wrapped or unwrapped instruments during busy schedules and shortages when sterile instruments need to be replenished. While the 325°F low-temperature cycle allows processing of heat-sensitive instruments and the veterinary surgical packs that utilize multi-use wraps and drapes. Combined with a waterless sterilization environment this level of temperature control maximizes the life span of your valuable instruments and reusable textiles.
RH-ProVET-9
RapidHeat ProVET advantages and features in a smaller, ease of mobility compact design.
- Processes up to 120 Instruments or 1 to 2 surgical packs
- No more wet surgical packs or pouches, uses no water
- Custom 325°F cycle for all your sterilization needs
- 375° cycle for “Immediate-Use” fast Instrument sterilization
- Simple and easy Touch-screen operation
- 65% more energy efficient than steam
- Non-Corrosive waterless environment
- No extensive maintenance – unlike steam sterilization
- Perfect for small veterinary practices and mobile veterinary services
| Electrical Rating | |
| 115 VAC | 120 VAC +/- 10%, 60Hz, 12 Amps • 1400 Watts warm-up, 300 Watts operating Transient Over-Voltage Category II Applies |
| 230 VAC | 230 VAC +/- 10%, 50/60Hz, 6 Amps • 1400 Watts warm-up, 300 Watts operating Transient Over-Voltage Category II Applies |
| Instrument/Material Compatibility | Identical Compatibility of Materials and Instruments for RH-Pro9 and RH-Pro11 Instrument Sterilization |
| Weight | 68.2 pounds (31 kg) |
| Width (OD) | 19.63” (572mm) |
| Depth (OD) | 20.00” (508mm) |
| Height (OD) | 13.75” (349mm) |
| Chamber Dimension | 9.5” (241mm) W • 15.6” (396mm) D 7.85″ (199mm) H |
| Chamber Capacity | 1163 cubic inches • (5 gal/19 liters) |
| Instrument Tray (ID) | 7.3” (76mm) W • 12” (305mm) D • .85” (22mm) H |
| Instrument Tray Capacity (Total) | 223 sq. inches (3 Trays) |
| Load Capacity | |
| Veterinary Surgical Packs | 1 Large Pack @ 1200g/Pack or 1-2 Small Packs @ 700g/Pack |
| Unwrapped | 2.4 kg; 120 Instruments |
| Handpieces (Unwrapped and Wrapped) | 15 Handpieces; 5 per Tray |
| Wrapped Instruments | 2.4 kg; 8-10 Instruments/Pouch; 4 Pouches/Tray; 3 Trays/Load Total Instruments/Load: 120 |
| Wrapped Cassettes 5.5” x 8” x 1.5” | 3 Cassettes (Total: 24 Instruments) |
| Wrapped Cassettes 8” x 11” x 1.5” | No 8″ x 11″ cassettes |
| Safety Certifications | UL, CE, US |
| FDA 510(k) | K872643A; K881371 |
| Warranty | 3-Years (Parts & Labor) |
Sterilization Cycle Times
Total sterilization processing times / 325° Veterinary Cycles
- Veterinary Surgical Packs – 150 minutes
- Unwrapped Instruments – 30 Minutes
- Wrapped / Pouched Instruments – 30 Minutes
- Wrapped Cassettes – 60 Minutes
Total sterilization processing times / 375° Immediate Use Cycle
- Unwrapped Instruments – 15 Minutes
- Wrapped / Pouched Instruments – 15 Minutes
The RapidHeat RH-Pro Advantage
No Dry Cycle
Improves Instrument Turnaround Time and removes the threat of environmental contamination and instrument corrosion from wet instruments.
No Water
Saves Time & Improves Patient Safety – With no water required, the potential for contamination from improperly cleaned water reservoirs is eliminated.
No Extensive Maintenance
There is no costly and time-consuming maintenance – Only a few minutes a week is needed to ensure the safe and effective operation of an RH-Pro Sterilizer.
